Automating with STEP 7 in STL and SCL
SIMATIC S7-300/400 Programmable Controllers
6. Edition July 2012
553 Pages, Hardcover
168 Pictures
147 tables
Practical Approach Book
Short Description
Elements and applications of the text-oriented programming languages STL and SCL are described for use with SIMATIC S7 including the applications with PROFINET and for communication over industrial ethernet. Users get many examples based on existing industrial applications.
- Out of print -
Further versions
SIMATIC is the worldwide established automation system for implementing industrial control systems for machines, manufacturing plants and industrial processes. Relevant open-loop and closed-loop control tasks are formulated in various programming languages with the programming software STEP 7.
Now in its sixth edition, this book gives an introduction into the latest version of engineering software STEP 7 (basic version) . It describes elements and applications of text-oriented programming languages statement list (STL) and structured control language (SCL) for use with both SIMATIC S7-300 and SIMATIC S7-400, including the new applications with PROFINET and for communication over industrial Ethernet. It is aimed at all users of SIMATIC S7 controllers.
First-time users are introduced to the field of programmable controllers, while advanced users learn about specific applications of the SIMATIC S7 automation system.
All programming examples found in the book - and even a few extra examples - are available at the download area of the publisher's website.
Programming Languages STL and SCL
Data Types
Binary and Digital STL Operations
Program Flow Control
Program Execution
Indirect Addressing in STL
SCL Control Statements
SCL Standard Functions
S5/S7 Converters
