Electronic Circuit Analysis and Design
This revised and expanded edition emphasizes the basic concepts underlying the analysis and design of all discrete and integrated circuits. Contains an extensive treatment of semiconductor fundamentals; new material on power supplies and Schottky barrier diodes including useful models for diodes in avalanche breakdown and cutoff; a more accurate linear model for the biopolar transistor; the concept of the Early voltage; and an improved account of frequency response. Features two new chapters devoted to the operational amplifier and its specifications and the use of the op-amp, with a number of its important applications such as voltage references, comparators, differentiators and intergrators. Many of the examples and all of the problems are new.
Bipolar and Field-Effect Transistors.
Transistor dc Models.
Designing for a Stable Operating Point.
Small-Signal Circuit Models.
Single-Stage Amplifiers at Mid-Frequencies.
Single-Stage Amplifiers at Low and High Frequencies.
Multistage Amplifiers.
The Operational Amplifier.
Applications of Operational Amplifiers.
Appendices.
Index.
